[Gurvy522]

oh good! I wanted to be sure nobody was profiteering your bracket! I bought one from you last month but my kids found it and have lost it, so I might become an ebay customer too!

Its a great deal for anyone else. Before I saw this listed today I re-ordered "cam-bracket-final-v2-ABS.step " from an online shop for pretty much the same price... but it was SLS nylon 12, do you think that is a good enough material? Thank you!

Technically people can profit off of it if they want to. I honestly don't care, lol. It's free here for those that want to print it, that's all that matters.

Yeah, nylon is great, pretty much any high-temp material will do fine, such as nylon, ABS, PETG. Even PC would work.

Sponsored



[hemlockz]

Do you remember what size of screw you used to attach the brackets to the grille's plastic holes? I don't want to get too big and crack the plastic but don't want to go too small so they don't bite deep enough, thanks!



[Gurvy522]

Do you remember what size of screw you used to attach the brackets to the grille's plastic holes? I don't want to get too big and crack the plastic but don't want to go too small so they don't bite deep enough, thanks!

Pretty sure they're standard coarse-threaded M5 screws.

I definitely remember it being a bit tight. On a brand new grill those are fresh holes so the threads are gonna cut in a bit.



[demelob]

Pretty sure they're standard coarse-threaded M5 screws.

I definitely remember it being a bit tight. On a brand new grill those are fresh holes so the threads are gonna cut in a bit.

@Gurvy522 Two questions for you, if you don't mind. Are you willing to sell and ship your brackets? I'm in Canada. Also, did your model come with a camera? I'm looking at a way to plug that hole with something cosmetically pleasing, since my model does not come with the front facing camera.



[Gurvy522]

@Gurvy522 Two questions for you, if you don't mind. Are you willing to sell and ship your brackets? I'm in Canada. Also, did your model come with a camera? I'm looking at a way to plug that hole with something cosmetically pleasing, since my model does not come with the front facing camera.

I made a small 3D printed plug for someone else that also didn't have a front facing camera. I could dig it up and share the file here. It just press fits in to cover the hole.

As far as the brackets, I only made two sets to meet the order minimum for powder coating. My recommendation that I've given others on this forum is to use the design and have them manufactured locally or by SCS.



[demelob]

I made a small 3D printed plug for someone else that also didn't have a front facing camera. I could dig it up and share the file here. It just press fits in to cover the hole.

As far as the brackets, I only made two sets to meet the order minimum for powder coating. My recommendation that I've given others on this forum is to use the design and have them manufactured locally or by SCS.

If you could dig it up, it would be much appreciated!



[demelob]

I made a small 3D printed plug for someone else that also didn't have a front facing camera. I could dig it up and share the file here. It just press fits in to cover the hole.

As far as the brackets, I only made two sets to meet the order minimum for powder coating. My recommendation that I've given others on this forum is to use the design and have them manufactured locally or by SCS.

Hey @Gurvy522. Any luck digging up the file? Much appreciated.
